| The injector at the heart of Merlin is of the pintle type that was first used in the Apollo Lunar Module landing engine (LMDE). Propellants are fed by a single-shaft, dual-impeller turbopump. The turbopump also provides high-pressure fluid for the hydraulic actuators, which then recycles into the low-pressure inlet. This eliminates the need for a separate hydraulic drive system and means that thrust vectoring control failure by running out of hydraulic fluid is not possible. |
||||||||||||||||||||||||||||||||||||||||
|
